SMART board dimensions

The SMART Board RX Series 65”–75” displays (RX265, RX275) feature VESA mounting patterns of 600x400 mm (65") or 800x400 mm (75") and weigh between 92.6 and 124 lb. The SMART electric height-adjustable wall stand (WSE-500) provides 26" of vertical travel for these displays.

Key RX Series Display Dimensions (approximate):

• 65" (RX265): ~58.5" W x 35.9" H x 3.6" D. Weight: ~92.6 lb.

• 75" (RX275): ~74.6" W x 43.4" H x 3.7" D. Weight: ~124 lb.

• Mounting VESA: M8; 600x400mm (65") or 800x400mm (75").

SMART Electric Height-Adjustable Wall Stand (WSE-500) Details:

• Adjustment Range: 26" (65 cm) of electric-powered height adjustment.

• Weight Capacity: Supports displays weighing up to 254 lb (115 kg).

• Safety Features: Includes collision detection, reversing if an obstruction is met.
